Style Hot Air Blowing Style Blowing Nozzle:350W θ4mm
Airflow Rate 2~12L/min(8STEP)
Air Pump. Vacuum Pump 내장
Nozzle Trace Range X.Y0~50mm Z 25mm
Temperature Control Adjustable By KNOB On Panel
Timer Control Adjustable By KNOB On Panel : MAX.5 MIN
Size Of Board TO Process Y Direction 420mm, X Direction No Limit
Mode 4 Modes, Std. Low. Slow. PGA/BGA
Power. Electricity AC 100, 120, 220V & Others. 360W
Dimensions W:300mm H:310mm D:450mm
Weight 9KGS
